Product Details:
Payment & Shipping Terms:
|
| Antistatic Value: | 10^6 -10^9, 10^8-10^11, 10^3-10^5 | Permanent Antistatic: | 10^6 - 10^9, 10^8-10^11, 10^3-10^5 |
|---|---|---|---|
| Color: | Black, Transparent, Etc | Hardness: | Rigid |
| Application: | Vacuum Forming, Packaging, Thermoforming, Printing ... | Thickness Range: | 0.15mm - 1.8mm |
| High Light: | apet plastic sheet,pet plastic film |
||
Material:PET
Type:Release Film
Usage:Packaging Film
Feature:Moisture Proof
Hardness:Rigid
Processing Type:Multiple Extrusion
Transparency:Transparent
Place of Origin:Fujian, China (Mainland), China
Brand Name:FXD
Model Number:PET-130121
color:any
Packaging Details:Packing in roll (3" ro 6" core; 50Kg/roll normally) or sheets on pallets
Delivery Time:within 2 weeks
| PROPERTY | UNIT | SA coated | Print level |
Antiblock silicon free |
Antistatic silicon free |
ESD | conductive |
| THICKNESS OF FILM TESTED | mm | 0.15~ 1.8 | 0.3~0.6 | 0.15~1.8 | 0.25~1.8 | 0.25~1.8 | 0.25~1.8 |
| WIDTH | mm | 350~ 1400 | 350~ 1300 | 600~ 1400 | 600~ 1400 | 600~ 1400 | 600~ 1400 |
| DIAMETER | 300~ 800 | 300~ 800 | 300~ 800 | 300~ 800 | 300~ 800 | 300~ 800 | |
| DENSITY | g/cm3 | 1.34 | 1.34 | 1.34 | 1.34 | 1.34 | 1.34 |
| HAZE. | % | 0.7(0.3mm) | 0.7(0.3mm) | 0.8(0.3mm) | 2.0(0.3mm) | 2.0(0.3mm) | 2.0(0.3mm) |
| TOTAL LIGHT TRANSMITTANCE | % | 92(0.3mm) | 91(0.3mm) | 91(0.3mm) | 89(0.3mm) | 89(0.3mm) | 89(0.3mm) |
| TENSILE STRENGTH @YIELD | |||||||
| MD | kg/cm2 | >450 | >450 | >450 | >450 | >450 | >450 |
| TD | kg/cm2 | >450 | >450 | >450 | >450 | >450 | >450 |
| TENSILE MODULUS OF AUTYOUNG | |||||||
| MD | kg/cm2 | >17000 | >17000 | >17000 | >17000 | >17000 | >17000 |
| TD | kg/cm2 | >17000 | >17000 | >17000 | >17000 | >17000 | >17000 |
| ELONGATION @YILED | |||||||
| MD | % | >3.0 | >3.0 | >3.0 | >3.0 | >3.0 | >3.0 |
| TD | % | >3.0 | >3.0 | >3.0 | >3.0 | >3.0 | >3.0 |
| DART IMPACT | |||||||
| LOAD CELL 15KN | g/mm | >1600 | >1600 | >1600 | >1600 | >1600 | >1600 |
| DIACLAMP | |||||||
| THERMAL GLASS TRANSITION | |||||||
| TEMPERATURE | (℃) | 68 | 68 | 68 | 68 | 68 | 68 |
| CRYSTAL TEMPERATURE | (℃) | 125 | 125 | 125 | 125 | 125 | 125 |
| MELITING TEMPERATURE | (℃) | 248 | 248 | 248 | 248 | 248 | 248 |
| RECRYSTAL TEMPERATURE | (℃) | 181 | 181 | 181 | 181 | 181 | 181 |
| ANTI-STATIC RESISTTVTTY | (Ω) | 109-1011 | 106-109 | <106 | |||
| RESISTTVTTY, SURFACE(HUMIDITY (50%±2%) (25℃) | |||||||
| Dyne--SURFACE | 38-40 |
This information contained in this bulletin is furnished without warranty,repreaentation,inducement of license of and kind, except that isaccurate to the best of FAR EASTERN'S knowledge or obtained from sources believed by FAR EASTERN to be accurate. And FAR EASTERNdoes not assume any legal responsibility for use or reliance upon same.Customers are encouraged to count their own tests.Before using my product, read it's label.
